XtrAlign HY laser

Features of XtrAlign HY lasers

Xtra tough industrial alignment lasers

Highest visibility

Manually focusable

Wide range of opening angles

Practically unbreakable

Dust- and waterproof

Configurations

XtrAlign HY line lasers

XtrAlign HY crosshair lasers

XtrAlign HY point lasers

Technical data

Laser data

Electronics data

Housing data

XtrAlign laser series

Accessories for XtrAlign HY lasers

Application examples for XtrAlign HY lasers

Diode lasers of XtrAlign HY series are designed to withstand the day to day use in harsh industrial environment. The waterproof stainless steel housing protects laser diode, electronic circuitry and precision optics. The laser diode is galvanically seperated from the power supply, which makes the laser extremely resistant to voltage peaks or current variations.

Key figures

0.1

mm/m laser line straightness

IP67

enclosure rating

IK10

impact resistance

>29900

hours of service life

LAP XtrAlign HY laser‘s bright green
lines, points and crosshairs are visible
even on wet, dark or multicoloured
surfaces. Laser power up to
40 mW illuminates even long lines.

Adjust the brightest possible spot,
cross or laser line with minimum
width for your application. Readjust
without tools after changing the projection
distance.

Select the line length for your application.
Get the maximal brightness at
the lowest possible laser class. Increase
safety by ending the laser beam
within your working space.

IK10 is the highest rating to define
the resistance to impacts by kinetic
energy. XtrAlign lasers have to withstand
the impact of a 5 kg steel free
fall hammer. 5 times. Tough enough?

You need lasers for use in the desert
or offshore ? Try LAP XtrAlign series.
The enclosure rating is IP67.
One restriction only: obviously you
have to keep the beam exit clean.

Models	Laser power	Line length @80°	Laser class @80°	@40°	@30°	@20°	@10°
LAP 1 HYL	1 mW	up to 1 m	1	1	1	1	1
LAP 3 HYL	3 mW	up to 2 m	1	1	2	2	2
LAP 5 HYL	5 mW	up to 4 m	1	2	2	2	2
LAP 10 HYL	10 mW	up to 6 m	2	2	2M	2M	2M
LAP 15 HYL	15 mW	up to 10 m	2	2M	2M	2M	3R
LAP 30 HYL	30 mW	up to 20 m	2M	3R	3R	3R	3R
LAP 40 HYL	40 mW	up to 30 m	3R	3R	3R	3R	3R

Models	Laser power	Laser class @62°	Laser class @38°
LAP 1 HYX	1 mW	1	1
LAP 3 HYX	3 mW	1	1
LAP 5 HYX	5 mW	2	1
LAP 10 HYX	10 mW	2	2
LAP 15 HYX	15 mW	2	2
LAP 30 HYX	30 mW	2M	2M
LAP 40 HYX	40 mW	2M	2M

Models	Laser power	Laser class
LAP 1 HYP	1 mW	2
LAP 3 HYP	3 mW	3R
LAP 5 HYP	5 mW	3R
LAP 10 HYP	10 mW	3B
LAP 15 HYP	15 mW	3B
LAP 30 HYP	30 mW	3B
LAP 40 HYP	40 mW	3B

Laser type	diode
Wavelength	520 nm
Laser color	green
Divergence	0.5 mrad
Laser power	1 ... 40 mW

Enclosure rating	IP 67
Shock resistance	IK 10
Dimensions	Length 140 mm × ø 25 mm (front) / 20 mm (back)
Weight	220 g
Ambient conditions	-10 ... +40 °C, 35 ... 90 % rel. humidity (non condensing)

Play Video

Become acquainted with the alignment lasers of XtrAlign series and their special features.

Brackets

B2-HD

B2-HD-K

B2-HD + BKK

B2-FD-J

B2-FD

B3-HD

B5-HD-F

B5-HD

Show all Show less

Power supply and connectors

Angled Connector 90° 24V

Power Supply for 24V lasers

Operating Voltage DC

12 ... 30 VDC

Operating Voltage AC

15 ... 20 VAC

Power consumption

M 12, 4-core
